mtCyclones

There is no single best cyclone for every application.

Why it matters

Where It Pays To Use mtCyclones

Cyclones often sit at high-leverage points in the flowsheet. Getting the duty and configuration right can reduce misplaced material, stabilise downstream feed and prevent a small classification problem from becoming a plant-wide constraint.

Get in touch

How it works

Feed enters under pressure
Outer vortex moves down
Inner vortex moves up
Two product streams form

A hydrocyclone can keep running while its cut drifts, its underflow ropes or valuable material reports to the wrong stream. Because the separation happens inside a closed vessel, small changes in feed, pressure, wear or configuration can quietly affect recovery, throughput and downstream performance.

Typical mtCyclone Applications

Diameter, cone angle, vortex finder, spigot, operating pressure and feed density all influence capacity, cut point and separation sharpness. Mineral Technologies matches these variables to the job the cyclone needs to perform. Only by matching the configuration to your orebody DNA a cyclone can really perform at its best.

75 – 900 mm nominal diameters
Broad flow-capacity range
Multiple cone-angle options
Easily interchangeable spigots and vortex finders
Vertical or inclined installation
Rubber, polyurethane or ceramic liners
Fibreglass or steel construction

The right cut We match cyclone geometry and operating conditions to the particle separation your process actually requires.
Stable performance Reducing the risk of roping, excessive spraying and overloaded cyclones disrupting the wider circuit is where our well configured cyclones shine.

Lower operating risk We use construction and liner materials around ore abrasiveness, placement, maintenance access and expected wear keeping mtCyclones in the game for much longer.
Spares, on hand and ready to go mtCyclones are more than the equipment you install – they come with our commitment to keep you running. Every spare part is kept in stock and can be exchanged in minutes thanks to the product‘s design. Our experts also help you spot problems before they occur.

Configurations

Model	Diameter	Flow range per cyclone
CY75	75 mm	3 – 17 m³/h
CY100	100 mm	5 – 25 m³/h
CY125	125 mm	8 – 40 m³/h
CY180	180 mm	15 – 70 m³/h
CY250	250 mm	28 – 110 m³/h
CY350	350 mm	45 – 210 m³/h
CY500	500 mm	110 – 490 m³/h
CY600	600 mm	210 – 710 m³/h
CY750	750 mm	380 – 1,000 m³/h
CY900	900 mm	580 – 1,100 m³/h

Right Size For You?

Mineral Technologies offers mtCyclones across a wide range of capacities and applications. Reach out and inquire in cases where you're application specs are different.
